OSW FIRE

OSW FOREST FIRE

especially for forest and vegetation fire fighting

OSW FIRE im Einsatz

Advantages

  • Signalling colouring with high visibility in difficult terrain
  • Low roll size diameter (ca. 25 mm / 15 m roll)
  • Extreme low weight to relieve fire fighting forces
  • Very good kink radius for high flexibility in tough terrain
  • „Self protection“ due to percolating effect flame test:
    10 min at 960 °C according to DIN 14811)
  • Water loss only 4.8 % / Working pressure 9 bar
    (made by 15m-length) – self wetting
  • low pressure loss due to smooth EPDM-rubberlined
  • Root resistant
  • Cold resistance: up to – 40 °C
  • Heat resistance: up to + 100 °C

Hose construction

  • Inside: high-quality, very light synthetic rubber on the basis of EPDM
  • Outside: jacket of 100 % high tenacity synthetic polyester yarn (4 different colour possible), circular-woven twill weave, warp and weft threads multiple twisted with percolation-effect (continuously needled)

Colours



Applicable Standards

  • Manufactured according to DIN 14811 Class 1 and Australian Standard AS2792
  • used in Germany, Greece, USA, Australia, Argentina, etc.

Service

  • Individual marking possible
  • Binding with various coupling types
  • with extended impact, abrasion and wetness protection cuff over the binding
OSW FIRE im Einsatz
OSW FIRE im Einsatz
OSW FIRE im Einsatz

Technical Details

The data regarding bursting pressure and working pressure refer only to the pure hose without couplings. Changes in technical specification without prior notice.

Diameter
Inch
Diameter
mm
Weight
(+/– 5 %)
g/m
Bursting
pressure
bar
Working
Pressure (1:3)
bar
Wall
Thickness
mm
Bending
Radius
mm
Theo. Tensile
Strength
kg
125150100331,602502.300XXXX
