OSW GARDEN
Efficient and convenient hose for gardening

Advantages
- Dimensional stability due to woven monofilament yarn, which makes the hose– resistant to kinking and twisting
- extremely high pressure resistance due to strong fabric construction
- very low weight for easier handling
- very good kink/bending radius for high flexibility
- high-quality EPDM-rubberlining is extremly resistant to aging, ozone and UV radiation
- environmentally friendly – EPDM is recyclable, free from harmful additives
- cold resistance: down to – 40 °C / heat resistance: up to + 100 °C (for water)
- innovative and modern design (haptic effect)
Construction
-
Inside: high-quality, very light synthetic rubber on the basis of EPDM
-
Outside: jacket of 100 % high tenacity synthetic polyester yarn with specially woven monofilament threads in the weft, circular-woven twill weave, warp and weft threads multiple twisteds
Colours
Sizes & length
- Available standard lengths: 15 m, 20 m, 25 m, 30 m, 45 m, 60 m
- Custom lengths are possible
- Available in diameters of 1/2“ and 3/4”
Service
- hoses can be connected without couplings or with high-quality sustainable metal couplings
- individual length sections are possible
- optionally also available: couplings, spray nozzle, plug-in nipple, wall bracket, hose reel etc.



Technical Details
The data regarding bursting pressure and working pressure refer only to the pure hose without couplings. Changes in technical specification without prior notice.
Diameter Inch | Diameter mm | Bursting Pressure bar | Working Pressure bar | Theo. Tensile Strength t | Wall Thickness mm | Weight g/m (+/– 5 %) |
---|---|---|---|---|---|---|
1/2 | 13 | > 90 | 4,5 – 6,0 | > 3 | 1,80 | 85 |
3/4 | in preparation | in preparation | in preparation | in preparation | in preparation | in preparation |
